Commercial poultry houses continuously discharge large volumes of warm ventilation air. Instead of releasing this airflow directly to the outside, a properly designed drying system can guide suitable exhaust air into the manure dryer to support moisture removal.
Lonsin’s Poultry Manure Dryer with Waste Heat Recovery is designed for layer farms, broiler farms, duck farms, and centralized poultry manure treatment projects that want to reduce dependence on separate heating fuel.
The system connects poultry house ventilation fans with a continuous multi-layer manure drying line. Fresh manure is collected, conveyed, distributed across drying layers, and exposed to controlled warm airflow. Moisture is removed continuously, helping reduce wet manure storage, transport weight, odor pressure, and downstream handling difficulty.
The dryer can use poultry house exhaust air as the primary drying air source where farm conditions are suitable. For colder weather, high humidity, enclosed installations, or higher-capacity projects, independent heating can be added as a supplemental option.
Get a Waste Heat Recovery Assessment
Fresh poultry manure usually contains approximately 70–80% moisture. This high water content increases storage volume, hauling cost, odor risk, and labor pressure.
A conventional drying system may rely mainly on biomass, gas, LPG, coal, or electric heating. A waste heat recovery configuration uses the warm air already discharged by poultry house ventilation fans to support the drying process.
Poultry House Ventilation Fans
↓
Air Collection Hood / Duct Connection
↓
Dryer Air Distribution Section
↓
Multi-Layer Manure Drying Chamber
↓
Moisture Removal and Exhaust Handling
↓
Dry Manure Storage / Fertilizer Processing / Pelletizing
This approach does not eliminate all energy consumption. Conveyors, distribution systems, control panels, sensors, fans, and optional auxiliary heating still require power. However, using available poultry house exhaust air can reduce supplemental heating demand compared with a dryer that depends entirely on a separate fuel source.
Fresh manure is collected from manure belts, scraper systems, pits, or centralized transfer points. The material is moved toward the drying system through a planned conveying route.
A sealed conveyor transfers manure from the poultry house collection area to the dryer feed section. This helps reduce exposed wet manure during handling and supports a more organized manure management process.
Warm exhaust air from poultry house ventilation fans is collected through hoods, ducts, or a plenum connection. The airflow route is designed according to fan location, air volume, dryer distance, and available installation space.
Before entering the drying section, manure is spread evenly across the conveyor width. A stable material layer improves airflow contact and helps reduce uneven drying.
The manure moves through one or more perforated chain-plate drying layers. Warm airflow passes through the material bed and removes moisture during continuous conveyance.
After drying, manure can be discharged to covered storage, bagging equipment, fertilizer processing machinery, or pelletizing lines.
A poultry manure dryer with waste heat recovery is especially suitable for farms that have continuous ventilation airflow and regular daily manure output.
| Farm Condition | Waste Heat Recovery Suitability |
|---|---|
| Layer farm with multiple poultry houses | Highly suitable |
| Poultry houses with continuous ventilation fans | Highly suitable |
| Centralized manure collection system | Suitable |
| Stable daily manure output | Suitable |
| Dryer located close to poultry houses | More favorable |
| Hot or warm climate | More favorable |
| Cold, rainy, or highly humid climate | May require supplemental heating |
| Long ducting distance between houses and dryer | Requires detailed airflow assessment |
| High-capacity centralized manure project | Suitable with engineered ducting and auxiliary heat options |
A preliminary project assessment should consider:
Number of poultry houses
Number and size of ventilation fans
Fan airflow direction and operating schedule
Distance between fan outlets and dryer location
Daily fresh manure output
Input moisture content
Local seasonal temperature and humidity
Available installation length and height
Preferred final use of dried manure
| Parameter | Reference System A | Reference System B | Custom Project Option |
|---|---|---|---|
| Daily processing capacity | 6,000 kg/day | 12,500 kg/day | Designed around farm output |
| Input moisture | Approx. 75–80% | Approx. 75–80% | Up to 80% |
| Target output moisture | ≤20% | ≤20% | 10–20% target range |
| Drying layers | Single-tier | Double-tier | 1–4 tiers available |
| Installed power | 45 kW | 90 kW | Customized |
| Reference running consumption | Approx. 30 kWh/hour | Approx. 37.5 kWh/hour | Depends on layout and heat source |
| Equipment footprint | 30 m × 4.5 m × 3 m | 30 m × 4.5 m × 6 m | Adjusted to site space |
| Main heat source | Poultry house exhaust air | Poultry house exhaust air | Waste heat + optional auxiliary heat |
| Control level | Basic automation | Full automation with alarm | Manual to fully automatic |
These are reference configurations only. Final capacity, energy demand, drying layers, machine dimensions, and airflow design should be confirmed according to actual farm conditions.
This option is suitable when poultry house fan outlets are close to the dryer installation area.
Poultry House Fans
↓
Short Duct Connection
↓
Dryer Air Inlet
↓
Drying Layers
↓
Exhaust Outlet
Best for:
Compact layer farm layouts
Poultry houses located near the manure treatment area
Projects with short ducting routes
Farms seeking a simpler airflow connection
This option collects airflow from multiple poultry houses before directing it toward the dryer.
Multiple Poultry Houses
↓
Fan Exhaust Collection Ducts
↓
Central Air Plenum
↓
Dryer Air Distribution Section
↓
Multi-Layer Drying System
Best for:
Multi-house layer farms
Centralized manure treatment buildings
Large poultry groups
Projects requiring more balanced airflow management
This option uses poultry house exhaust air as the main drying support while adding another heat source during unfavorable weather or peak-capacity periods.
Available auxiliary heating options include:
Biomass or straw heating
Natural gas
LPG
Coal or briquette heating
Electric heating
Best for:
Cold regions
Rainy or humid climates
Projects requiring stable year-round output moisture
Enclosed drying installations
High-capacity manure treatment projects
Warm air from poultry houses can reduce the amount of additional heating required for moisture removal.
Ventilation fans are already part of modern poultry house operation. A waste heat recovery design allows their exhaust airflow to support manure treatment instead of being used only for house ventilation.
Continuous drying helps reduce the mass and volume of manure that must be stored before transport or processing.
Lower-moisture manure weighs less than fresh manure. This can reduce wet material handling and improve loading efficiency.
Sealed conveying and continuous drying can reduce the time wet manure remains exposed around poultry houses and transfer points.
Dried manure is easier to direct into covered storage, fertilizer processing, bagging, screening, or pelletizing systems.
| Item | Waste Heat Recovery Dryer | Independent Heating Dryer |
|---|---|---|
| Main drying air source | Poultry house exhaust air | Biomass, gas, LPG, coal, or electric heating |
| Fuel requirement | Lower where warm exhaust air is sufficient | Higher dependence on purchased energy |
| Best application | Poultry farms with continuous ventilation airflow | Farms without sufficient warm exhaust air |
| Seasonal sensitivity | Higher | Lower with controlled heat supply |
| Installation consideration | Requires fan and duct integration | Requires fuel, heating unit, and combustion or power system |
| Operating flexibility | Can be combined with auxiliary heating | Suitable as standalone heat source |
| Recommended use | Layer farms and centralized poultry projects | Cold-climate, enclosed, or high-output projects |
For many commercial projects, the most practical solution is not waste heat only or independent heat only. It is a hybrid design that uses poultry house exhaust air whenever available and activates supplemental heating when required.
Layer farms often have continuous manure collection and stable ventilation operation. This makes them one of the most suitable applications for waste heat-supported manure drying.
Broiler projects may require additional evaluation because manure may contain bedding, feathers, or other materials. Drying parameters and feeding systems should be adapted accordingly.
Duck and goose manure may have higher moisture and different material characteristics. Waste heat can still support the drying process, but the final system should be designed around actual material condition.
Projects serving multiple poultry houses or multiple farm zones can use centralized ducting, conveying, drying, and storage systems.
Waste heat recovery dryers can prepare poultry manure for fertilizer screening, mixing, granulation, packaging, or other downstream processing steps.
Lonsin designs the system around the farm rather than requiring the farm to fit a fixed machine size.
Customization can include:
Daily manure handling capacity
Dryer length, width, and tier quantity
Fan air collection method
Duct routing and air distribution direction
Sealed conveying structure
Material distribution system
Waste heat-only or hybrid heat supply
Manual, semi-automatic, or fully automatic control
Temperature, humidity, and conveyor speed monitoring
Fault alarms and optional remote monitoring
Storage, bagging, fertilizer processing, or pelletizing connection
It depends on fan airflow, air temperature, local climate, poultry house operating conditions, manure moisture, and dryer capacity. In warm conditions with stable ventilation airflow, poultry house exhaust air can provide meaningful drying support. In cold or humid conditions, supplemental heating may be needed.
No. The system still requires power for conveyors, control systems, distribution equipment, and fans. Waste heat recovery mainly reduces the need for additional heating fuel where poultry house exhaust air is suitable.
Yes, but winter performance should be evaluated carefully. In colder climates, the system may require biomass, gas, LPG, electric, or other auxiliary heating to maintain stable drying results.
A shorter distance is generally more favorable because it reduces duct length, pressure loss, heat loss, and installation complexity. The final location should also consider manure collection routes, maintenance access, storage space, and local site conditions.
Yes. Multiple houses can be connected through a centralized ducting and air collection system when the project requires a larger manure treatment capacity.
Fresh poultry manure typically enters at approximately 70–80% moisture. The system can be designed to reduce moisture to 20% or below, depending on the heat source, airflow, material condition, operating hours, and final use requirement.
Yes. Dried poultry manure can be used as a feedstock for organic fertilizer processing, bagging, screening, blending, granulation, or pelletizing, subject to local regulations and product requirements.
Send us your approximate poultry farm information, and Lonsin will prepare a preliminary recommendation.
